Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
KBMS1
USB1
RJ45USB1
AUDIO1
COM1
JUSBV1
ATXPWR2
AT X P W R 1
LAN
PEX1 _1
PEX16_1
PEX1_2
PCI3
PCI2
PCI1
Codec
Super I/O
F_AUDIO1
J_PRINT1
FDD1
PA N E L 1
SYS_FAN1
JUSBV2
F_USB1F_USB2
SATA1 S ATA3 SATA5
S ATA2 S ATA4 SATA6
BIOS
JCMOS1
BAT
IDE1
DDR3_A1
DDR3_B1
DDR3_B2
Socket A M 3
DDR3_A2
CPU_FAN1
AMD
770
AMD
SB710
JSPDIFOUT1
Note: represents the 1■
st
pin.
