A770L3 BIOS Manual
25
Link ASPM
Options: Disabled (Default) / L0s / L1 / L0x & L1
Link Width (Port #02 Only)
Options: Auto (Default) / x1 / x2 / x4 / x8 / x16
Slot Power Limit, W (Port #02 Only)
Options: 75 (Default) / 0-255
NB-SB Port Features
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
NP NB-SB VC1 Traffic Support [Disabled]
NB-SB Link ASPM [Disalbed] Options
Disabled
L1
NB-SB Link ASPM
Options: Disabled (Default) / L1
NP NB-SB VC1 Traffic Support
Options: Disabled (Default) / Enabled
Primary Video Controller
This option allows you to select the video controller in charge.
Options: PCIE GFX0-GFX2-GPP-PCI (Default) / PCIE GFX2-GFX0-GPP-PCI /
PCIE GPP-GFX0-GFX2-PCI / PCI-PCIEGFX0-GFX2-GPP
