A780L3C
43
SPEC
Złącze główkowe wentylatora systemowego x1 Zasilanie wentylatora systemowego
Złącze główkowe kasowania CMOS x1
Złącze USB x2 Każde złącze obsługuje 2 porty USB na panelu przednim
Złącze zasilania (24 pinowe) x1
Złącze zasilania (4 pinowe) x1
Złącze Port drukarki x1 Każde złącze obsługuje 1 Port drukarki
Back Panel
I/O
Klawiatura PS/2 x1
Mysz PS/2 x1
Port VGA x1
Port LAN x1
Port USB x4
Gniazdo audio x3
Wymiary
płyty
182 mm (S) X 225 mm (W)
Funkcje
specjalne
Obsługa RAID 0 / 1 / 10
Obsluga
systemu
operacyjneg
o
Windows XP / Vista / 7 / 8
Biostar zastrzega sobie prawo dodawania lub odwoływania
obsługi dowolnego systemu operacyjnego bez
powiadomienia.
