Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM3
AMD Sempron / Athlon II / Phenom II
processors
(Maximum Watt: 95W)
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0
FSB
Support HyperTransport 3.0
Supports up to 3.2 GT/s Bandwidth
Chipset
AMD RS780L
AMD SB710
Super I/O
ITE 8721
Provides the most commonly used legacy
Super I/O functionality
Low Pin Count Interface
Environment Control initiatives
H/W Mon itor
ITE's "S mart Guardian" function
Main
Memory
DDR3 DIMM Slots x 2
Max Memory Capacity 8GB
Each DIMM supports 512MB/
1GB/2GB/4GB DDR3
Dual Channel Mode DDR3 memory modu le
Supports DDR3 800 / 1066 / 1333
Registered DIMM and ECC DIMM is not supported
Graphics Integrated in AMD RS780L Chipset
Max Shared V id eo Memory is 512 MB
DVI/HDCP support
IDE Integr ated IDE Contro lle r
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA II Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Version 2.0 s pecif icat ion co mp liant
LAN Realtek RTL 8103EL
10 / 100 Mb/s auto negotiation
Half / Full duplex capability
Sound ALC662
5.1 channels audio out
High Definition Audio
PCI Express Gen2 x16 slot x1 Supports PCI-E Gen2 x16 expansion cards
Slots
PCI slot x2 Supports PCI expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
IDE Connector x1 Each connector supports 2 IDE devices
SATA Connector x4 Each connector supports 1 SATA device
Front Panel Connector x1 Supports front panel facilities
On Board
Connectors
Front Audio Connector x1 Supports front panel audio function
