Biostar TA790GX3 A2+ Версия 5.x [12/71] B memory capacity

Motherboard Manual

B. Memory Capacity

DIMM Socket

Location

DDR2 Module

Total Mem ory

Size

DIMMA1 256MB/512MB/1GB/2GB/4GB

DIMMB1 256MB/512MB/1GB/2GB/4GB

DIMMA2 256MB/512MB/1GB/2GB/4GB

DIMMB2 256MB/512MB/1GB/2GB/4GB

Max is 16GB.

C. Dual Channel Memory installation

To trigger the Dual Channel function of the motherboard, the memory module

must meet the following requirements:

Install memory module of the same density in pairs, shown in the following

table.

Dual Channel Status

DIMMA1

DIMMB1 DIMMA2 DIMMB2

Enabled O O X X

Enabled X X O O

Enabled O O O O

(O means memory installed, X means memory not installed.)

The DRAM bus width of the memory module must be the same (x8 or

x16)
