TA790GXB A2+ BIOS Manual
30
6 T-Series Menu
This submenu allows you to change voltage and clock of various devices.
(However, we suggest you to use the default setting. Changing the voltage and clock
improperly may damage the device.)
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause system to malfunction.
=========== Automate OverClock System ===========
============ Manual OverClock System ============
OverClock Navigator [Normal]
Auto OverClock System [V6-Tech Engine]
CPU/HT Reference Clock(MHz) [200]
CPU Configuration [Auto]
ATIG Reference Clock(MHz) [100]
SB Reference Clock(MHz) [100]
Spread Spectrum [Disabled]
> CPU FID/VID Control
> Voltage Configuration
> Memory Configuration
> DRAM Timing Configuration
> Hyper Transport Configuration
Exit
Options
Normal
Automate OverClock
Manual OverClock
OverClock Navigator
OverClock .Navigator is designed for beginners in overclock field.
Based on many test and experiments from Biostar Engineer Team, OverClock
Navigator provides 3 default overclock configurations that are able to raise the
system performance.
Options: Normal (Default) / Automate OverClock / Manual OverClock
