A740G M2+ BIOS Manual
12
Hardware Health Configuration
This item sho ws the sys tem temperature, fan speed, and vo ltage information.
Advanced
Hardware Health Configuration
H/W Health Function [Enabled]
Shutdown Temperature [Disabled]
SYS
CPU Temperature
CPU FAN Speed
SYS FAN Speed
CPU Core
NB Voltage
+3.30V
+5.00V
+12.0V
DDR Voltage
HT Voltage
5VSB
VBAT
Temperature
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Enables Hardware
Health Monitoring
Device.
H/W Health Function
If yo u co mputer contains a mo nitoring system, it will show P C health status during
POST stage.
Options: Enabled (Default) / Disabled
Shutdown Temperature
This item allows you to set up the CPU shutdown Temperature. This item is only
effective under Windows 98 ACPI mode.
Options: Disabled (Default) / 70℃/158℉ / 60℃/140℉ / 65℃/149℉ / 75℃/158℉
/ 80℃/158℉ / 85℃/158℉ / 90℃/158℉ / 95℃/158℉
