Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM2+
AMD Sempron / Athlon / Athlon II / Phenom
/ Phenom II processors
(Maximum Watt: 95W)
AMD 64 Architecture enables 32 and 64 bit
computing
Supports Hyper Transport 2.0
FSB
Support HyperTransport 2.0
Supports up to 2 GT/s Bandwidth
Chipset
AMD 740G (A740G M2L+)
AMD 780L (A780LB)
AMD SB710
Super I/O
ITE 8718F
Provides the most commonly used legacy
Super I/O functionality
Low Pin Count Interface
Environment Control initiatives
H/W Monitor
ITE's "Smart Guardian" function
Main
Memory
DDR2 DIMM Slots x 2
Max Memory Capacity 8GB
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR2
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (by AM2+/AM3 CPU)
Registered DIMM and ECC DIMM is not supported
Graphics Integrated in AMD 740G Chipset
Max Shared Video Memory is 512MB
Avivo support
IDE Integrated IDE Controller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA II Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Version 2.0 specification compliant
LAN Realtek RTL 8102EL/8103EL/8106E 10 / 100 Mb/s auto negotiation
Sound ALC662
5.1 channels audio out
High Definition Audio
PCI Express X16 slot x1 Supports PCI-E X16 expansion cards
Slots
PCI slot x2 Supports PCI expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x4 Each connector supports 1 SATA devices
Front Panel Connector x1 Supports front panel facilities
On Board
Connectors
Front Audio Connector x1 Supports front panel audio function
