A770 A2G+ BIOS Manual
31
NB-SB Port Features
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
NP NB-SB VC1 Traffic Support [Disabled]
NB-SB Link ASPM [Disabled]
Options
Disabled
L1
NB-SB Link ASPM
Options: Disabled (Default) / L1
NP NB-SB VC1 Traffic Support
Options: Disabled (Default) / Enabled
Primary Video Controller
This option allows you to select the video controller in charge.
Options: PCIE GFX0-GFX2-GPP-PCI (Default)
PCIE GFX2-GFX0-GPP-PCI
PCIE GPP-GFX0-GFX2-PCI
PCI-PCIEGFX0-GFX2-GPP
