TA770E/TA770XE/TA790XE BIOS Manual
21
5 Chipset Menu
This submenu allows you to configure the speci fic features of the chipset installed on
your system. This chipset manage bus speeds and access to system memory
resources, such as DRAM. It also coordinates communications with the PCI bus.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 198 5-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Scr een
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Options for SBAdvanced Chipset S ettings
> RX780 Configurat ion
> OnBoard Peripher als Configuration
> SouthBridge Conf iguration
Exit
SouthBridge Co nfig uration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 198 5-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Scr een
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
OHCI HC(Bus 0 Dev 18 Fn 0) [Enabled]
OHCI HC(Bus 0 Dev 18 Fn 1) [Enabled]
EHCI HC(Bus 0 Dev 18 Fn 2) [Enabled]
OHCI HC(Bus 0 Dev 19 Fn 0) [Enabled]
OHCI HC(Bus 0 Dev 19 Fn 1) [Enabled]
EHCI HC(Bus 0 Dev 19 Fn 2) [Enabled]
OHCI HC(Bus 0 Dev 20 Fn 5) [Enabled]
OnChip SATA Channe l [Enabled]
OnChip SATA Type [Native IDE]
SATA IDE Combined Mode [Enabled]
Power Saving Featu res [Disabled]
SouthBridge Chipse t Configuration
SB710 CIMx Version : 4.4.0
> SB Azalia Audio Configuration
Options
for SB HD Azalia
