Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
JKBMS
VGA
DVI
JUSB1
JUSBLAN1
JAUDIO1
BAT1
LAN
JAUDI OF
Codec
JCOM
FDD
JSFAN
JPANEL1
SATA1
SATA2
SATA3
SATA4
Super I/O
BI OS
JUSB2 JUSB3JUSB4
IDE
DIMMB1
DIMMA1
Socket AM2+
PCI2
PCI1
PEX16_ 1
GeForce
8100
J CDIN
JPRNT
JCMOS
JATXPWR1
JATXPWR2
JKB _PWR
JUSB PW R1
JCFAN
JUSBPWR2
Note: represents the 1■
st
pin.
