Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
JKBMS1
JUSB1
JUSBL AN2
JA U DI OF1
Codec
JCDIN1
Super I/O
JCOM1
JUSB4
JUSB3
JUSB2
JSFAN1
JPANEL1
SATA3
SATA4
SATA2
SATA1
FDD1
IDE1
JATXPWR1
JCFAN 1
Socket AM2+
GeForce
8200
LAN
PCI1
PCI2
PC I-EX1_1
PEX16_1
JSPDIF_OUT1
JCMOS1
JATXPWR2
VGA
DIMMA1
DIMMA2
BIOS
DVI
JAUDIO1
JPR NT1
JUSBPWR4
SATA5
SATA6
DIMMB1
DIMMB2
BAT1
JUSB5
JUSBPWR2
JKB_ PWR
Note: represents the 1■
st
pin.
