GF8100 M2+ TE/GF8200C M2+
39
SPECIFICA
Connettore SATA x4 Ciascun connettore supporta 1 unità SATA
Connettore pannello frontale x 1 Supporta i servizi del pannello frontale
Connettore audio frontale x1 Supporta la funzione audio pannello frontale
Connettore CD-in x1 Supporta la funzione input audio CD
Collettore ventolina C PU x1
Alimentazione ventolina CPU (con funzione Smart
Fan)
Collettore ventolina sistema x1 Alimentazione ventolina d i sistema
Collettore cancellaz ione CMOS x1
Connettore USB x3
Ciascun connettore supporta 2 porte USB
pannello frontale
Connettore alimentazione x1
(24 pin)
Connettore alimentazione x1
(4 pin)
Connettore Porta stampante x1 Ciascun connettore supporta 1 Porta stampante
Connettore Porta seriale x1
I/O
pannello
posteriore
Tas t iera PS /2 x 1
Mouse PS/2 x1
Porta VGA x1
Porta LAN x1
Porta USB x4
Connettore audio x3
Porta DVI x1
Dimension
i scheda
175 mm (larghezza) x 245 mm
(altezza)
Caratterist
iche
speciali
Supporto RAID 0 / 1 / 5 / 0+1
Supporto Hybrid SLI (by nVIDIA
driver)
Sistemi
operativi
supportati
Windows XP / VISTA
Biostar si riserva il diritto di aggiungere o
rimuovere il supporto di qualsiasi sistema
operativo senza preavviso.
