11
CPU Clock Selection: JCLK1
Audio Subsystem: JAUDIO1/ JCDIN1
1
2
JAUDIO1
(Front Audio Header)
1
JCDIN1
(CD-ROM Audio-In Header)
1
2
JAUDIO1
(Front Audio Header)
1
JCDIN1
(CD-ROM Audio-In Header)
JCLK1
Pin 1-2, 5-6 ==> 100 Mhz
Pin 2-3, 5-6 ==> 133 Mhz
(default)
Pin 2-3, 4-5 ==> 166Mhz
1
36
4
1
2
Pin1 ==> Mic In Pin2 ==> Ground
Pin3 ==> Mic Power Pin4 ==> Audio Power
Pin5 ==> RT Line Out Pin6 ==> RT Line Out
Pin7 ==> Reserved Pin8 ==> KEY
Pin9 ==> LFT Line Out Pin10 ==> LFT Line Out
JAUDIO1
12
Front Panel Audio Connector/ Jumper Block
910
Audio line out signals are routed
to the back panel audio line out connector.
Pin 5 and 6
==>
Pin 9 and 10
12
9
10
Audio line out and mic in signals are
available for front panel audio connectors.
