Biostar M7VIG Pro [3/55] English
![Biostar M7VIG Pro [3/55] English](/views2/1711949/page3/bg3.png)
M
M
M
o
o
o
t
t
t
h
h
h
e
e
e
r
r
r
b
b
b
o
o
o
a
a
a
r
r
r
d
d
d
D
D
D
e
e
e
s
s
s
c
c
c
r
r
r
i
i
i
p
p
p
t
t
t
i
i
i
o
o
o
n
n
n
1
English
M7VIG Pro Features
Use VIA VT8375 (KM266)/ VT8235 Chipset, Winbond W83697HF, LAN
Chip- VT6103 (optional).
Contains on board I/O facilities, which include one serial port, one VGA port,
a parallel port, a PS/2 mouse port, a PS/2 keyboard port, audio ports, USB
2.0 ports, a LAN port (optional) and a game port.
Supports the single AMD Socket A for Athlon™ (Thunderbird™) / Athlon
XP™ / Duron ™ processors running at 200/266 MHz Front Side Bus (FSB).
Supports Ultra 133/100/66/33, PIO modes, IDE hard disk drives, LBA
mode.
Supports 2 DDR 200/266 MHz (without ECC) devices, maximun memory
size up to 2GB.
Supports 2 SDR 100/133 MHz (without ECC) devices, maximun memory
size up to 2 GB.
Supports one CNR Slot (Type B only), three 32-bit PCI Bus slots, and one
AGP Slot.
Complies with PC Micro-ATX form factor specifications.
Supports popular operating systems such as Windows NT, Windows 2000,
Windows ME, Windows XP, LINUX and SCO UNIX.
AC’97 2.2 compatible.
High S/N ratio meets PC 99 requirements.
6CH DAC, applicable for leading motherboard chipsets.
Line-in phonejack share with rear out.
Supports front audio pin head functions.
Содержание
- English 3
- M7vig pro features 3
- Layout of m7vig pro 4
- Package contents 4
- Cpu installation 5
- Jcfan1 5
- Jsfan1 5
- Ddr dimm modules ddr1 2 6
- Sdr dimm modules sdr1 2 6
- Jumpers headers connectors slots 8
- Jatxpwr1 9
- Jcmos1 9
- Jdimmvolt 9
- Características del m7vig pro 13
- Español 13
- Contenido del paquete 14
- Disposición del m7vig pro 14
- Instalación de la cpu 15
- Jcfan1 15
- Jsfan1 15
- Módulo sdr dimm sdr1 2 16
- Módulos ddr dimm ddr1 2 16
- Conectores cabezales puentes y ranuras 18
- Jatxpwr1 19
- Jcmos1 19
- Jdimmvolt 19
- Jusb2 3 20
- Trouble shooting 23
- Solución de problemas 24
- M7vig pro bios setup 26
- Acpi support 27
- Apm support 27
- Bios setup 27
- Epa green pc support 27
- Introduction 27
- M7vig pro bios setup 27
- Plug and play support 27
- Ddr double data rate synchronous dram are supported 28
- Dram support 28
- Keystroke function 28
- M7vig pro bios setup 28
- Pci bus support 28
- Supported cpus 28
- This award bios also supports version 2 of the intel pci peripheral component interconnect local bus specification 28
- This award bios supports the amd socket cpu 28
- To quit the following table provides more detail about how to navigate in the setup program by using the keyboard 28
- Using setup 28
- Advanced bios features 29
- Figure 1 main menu 29
- M7vig pro bios setup 29
- Main menu 29
- Standard cmos features standard cmos features 29
- Advanced chipset features 30
- Frequency control 30
- Integrated peripherals 30
- Load optimized defaults 30
- M7vig pro bios setup 30
- Pc health status 30
- Pnp pci configurations 30
- Set supervisor password 30
- Exit without saving 31
- M7vig pro bios setup 31
- Save exit setup 31
- Set user password 31
- Upgrade bios 31
- Figure 2 standard cmos setup 32
- M7vig pro bios setup 32
- Standard cmos features 32
- Item options description 33
- M7vig pro bios setup 33
- Main menu selections 33
- Item item options description 34
- M7vig pro bios setup 34
- Advanced bios features 35
- Boot seq floppy setup 35
- Figure 3 advanced bios setup 35
- M7vig pro bios setup 35
- Virus warning virus warning 35
- Boot up numlock status 36
- Cpu internal cache 36
- Cpu l2 cache ecc checking 36
- External cache 36
- Gate a20 option 36
- M7vig pro bios setup 36
- Quick power on self test 36
- Typematic rate setting 36
- Apic mode 37
- M7vig pro bios setup 37
- Mps version control for os 37
- Security option 37
- Summary screen show 37
- Typematic delay msec 37
- Typematic rate chars sec 37
- Video bios shadow 37
- Advanced chipset features 38
- Dram clock drive control 38
- Figure 4 advanced chipset setup 38
- M7vig pro bios setup 38
- Agp p2p bridge control 39
- M7vig pro bios setup 39
- Cpu pci bus control 40
- M7vig pro bios setup 40
- M7vig pro bios setup 41
- Memory hole 41
- System bios cacheable 41
- Vga share memory size 41
- Video ram cacheable 41
- Figure 5 integrated peripherals 42
- Integrated peripherals 42
- M7vig pro bios setup 42
- Onchip ide control onchip ide control 42
- M7vig pro bios setup 43
- Onboard lan boot rom 43
- Onchip pci devic 43
- Onchip pci device 43
- Via 3043 onchip lan 43
- Via 3058 ac97 audio 43
- Via 3068 mc97 modem 43
- Ir transmission delay 44
- M7vig pro bios setup 44
- Onboard fdc controller 44
- Onboard serial port 1 44
- Onboard serial port 2 44
- Rxd txd active 44
- Super io devic 44
- Super io device 44
- The choices half default full use ir pins 44
- Uart mode select 44
- Ur2 duplex mode 44
- Ecp mode use dma 45
- Epp mode select 45
- Game port address 45
- Init display first 45
- M7vig pro bios setup 45
- Midi port address 45
- Midi port irq 45
- Onboard parallel port 45
- Onchip usb controller 45
- Parallel port mode 45
- M7vig pro bios setup 46
- Onboard usb controller 46
- Usb keyboard support 46
- Acpi function acpi function 47
- Acpi suspend type 47
- Figure 6 power management setup 47
- M7vig pro bios setup 47
- Power management 47
- Power management setup 47
- Hdd power down 48
- M7vig pro bios setup 48
- Max power saving 48
- Min power saving 48
- Suspend mode 48
- User defined default 48
- Video off method 48
- Video off option 48
- M7vig pro bios setup 49
- Modem use irq 49
- Soft off by pwr bttn 49
- State after power failure 49
- Wake up power on control 49
- M7vig pro bios setup 50
- Note if you have changed the setting you must let the system boot up until it goes to the operating system before this function work 50
- Reload global timer events reload global timer events 50
- Figure 7 pnp pci configurations 51
- M7vig pro bios setup 51
- Pnp os installed 51
- Pnp pci configurations 51
- Reset configuration data 51
- Irq resources 52
- M7vig pro bios setup 52
- Pci vga palette snoop 52
- Resources controlled by 52
- Assign irq for usb 53
- Assign irq for vga 53
- M7vig pro bios setup 53
- Cpu voltage 3 v 5v 12v 12v 5v 54
- Current cpu temperature current cpu temperature 54
- Current cpufan speed 54
- Current sysfan speed 54
- Figure 8 pc health status 54
- M7vig pro bios setup 54
- Pc health status 54
- Show h w monitor in post 54
- Auto detect dimm pci clk 55
- Cpu host pci clock 55
- Figure 9 frequency control 55
- Frequency control 55
- M7vig pro bios setup 55
- Spread spectrum 55
