K8T800-A7A
2
Super I/O
Chip: ITE 8705AF.
Low Pin Count Interface.
Provides the most commonly used legacy Super I/O
functionality.
Environment Control initiatives,
! H/W Monitor
! Fan Speed Controller
! ITE's "Smart Guardian" function
Operating System Supporting
Supports Windows 98 / Me / 2000 / XP.
Onboard AC’97 Sound CODEC
Chip: REALTEK ALC655.
Support 6 channels.
Supports S/PDIF out function.
Compliant with AC’97 Version 2.3 specification.
Onboard Serial ATA
Controller integrated in VT8237R Plus.
Supports RAID 0 and RAID 1 functions.
Supports 2 serial ATA (SATA) ports.
- Data transfer rates up to 150 MB/s.
- Compliant with SATA Version 1.0 specification.
10/100 LAN PHY
PHY: RTL8201BL / CL.
Supports 10 Mb/s and 100 Mb/s auto-negotiation.
Half/Full duplex capability.
Supports ACPI, PCI power management.
