A68I-350 DELUXE R2.0/A68I-450 DELUXE/A68I-E350 DELUXE
29
Japanese
仕様
CPU サポート
AMD E-450D (A68I-450 DELUXE)
AMD E-350D (A68I-350 DELUXE R2.0)
AMD E-350 (A68I-E350 DELUXE)
チップセット
AMD A68 FCH
メモリ
シングルチャンネル DDR3 800/ 1066 /1333 をサポート
(DDR3 1333 is only for A68I-450 DELUXE)
2 x DDR3 DIMM メモリ スロット、 最大 16GB メモリまでサポート
各 DIMM は、 非-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 モジュールをサポートしています
*サポートされているメモリのリストについては、
www.biostar.com.twを参照してください。
保存スペース
3x SATA 6Gb/s コネクタ, ネイティブ IDE & AHCI モード のサポート
LAN
Realtek RTL 8111F
10/ 100/ 1000 Mb/s オートネゴーシエーション、半/全 二重通信
オーディオ コーデッ
ク
ALC662
5.1 チャンネル, ハイ デフィニション オーディオ
USB
2x USB 3.0 ポート (後部 I/O に2つ)
6x USB 2.0 ポート (後部 I/O に2つ 及び 内蔵ヘッダー経由に4つ)
拡張スロット
1x PCIe 2.0 x16 スロット (x4)
後部 I/O
1x PS/2 キーボード
1x PS/2 マウス
1x HDMI ポート
1x VGA ポート
1x LAN ポート
2x USB 2.0 ポート
2x USB 3.0 ポート
3x オーディオ ジャック
内蔵 I/O
3x SATA 6.0Gb/s コネクタ
2x USB 2.0 ヘッダー (各ヘッダーは、2つの USB 2.0 ポートをサポートしています)
1x 4-Pin パワー コネクタ
1x 24-Pin パワー コネクタ
1x CPU ファン コネクタ
1x システム ファン コネクタ
1x フロント パネル ヘッダー
1x フロント オーディオ ヘッダー
1x クリア CMOS ヘッダー
1x プリンター ポート ヘッダー
1x シリアル ポート ヘッダー
1x S/PDIF アウト コネクタ
フォーム ファクタ
mini-ITX フォーム ファクタ、170 mm x 170 mm
サポート OS
Windows XP / Vista / 7 / 8
Biostar には、通知なしでサポート OS を変更する権限があります。
