Motherboard Manual
2
1.3 Motherboard Specifications
Specifications
CPU Support
A68N-5200: A6-5200 (Quad core 2.0GHz, 25W)
A68N-5000: A4-5000 (Quad core 1.5GHz, 15W)
A68N-3800: E2-3800 (Quad core 1.3 GHz, 15W)
A68N-2100: E1-2100 (Dual core 1.0 GHz, 9W)
Memory
Supports Single Channel DDR3 800/1066/1333/1600
(*A68N-2100 is only for DDR3 800/1066/1333)
2 x DDR3 DIMM Memory Slot, Max. Supports up to 16 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 module
* Please refer to www.biostar.com.tw
for Memory support list.
Storage 2x SATA 6Gb/s Connector, Supports Native IDE, AHCI Mode
LAN
Realtek RTL 8111G
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
Audio Codec ALC662, 5.1 Channels, High Definition Audio
USB
2x USB 3.0 port (2 on rear I/Os)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots 1x PCIe 2.0 x16 Slot (x4)
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x HDMI Port
1x VGA Port
1x LAN port
2x USB 2.0 Port
2x USB 3.0 Port
3x Audio Jack
Internal I/Os
2x SATA 6.0Gb/s Connector
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x Printer Port Header
1x Serial Port Header
1x S/PDIF out Connector
Form Factor mini-ITX Form Factor, 170 mm x 170 mm
OS Support
Windows XP / 7 / 8 / 8.1
Biostar reserves the right to add or remove support for any OS with or without
notice.
