Hardware Installation

1. Locate an optimum location for the WNRT-630. The best place

for your WNRT-630 is usually at the center of your wireless network,

with line of sight to all of your mobile stations.

2. Adjust the antennas of WNRT-630. Try to adjust them to a posi-

tion that can best cover your wireless network. The antenna’s posi-

tion will enhance the receiving sensitivity.

3. Connect RJ-45 cable to WNRT-630 LAN port. Connect one of the

LAN ports on WNRT-630 to your LAN switch/hub or a computer with

a RJ-45 cable.

4. Connect RJ-45 cable to WNRT-630 WAN port. Connect the

supplied Ethernet cable to xDSL/Cable Modem and the WAN port on

WNRT-630.

5. Plug in power adapter and connect to power source. After

power on, WNRT-630 will start to operate.

Note

ONLY use the 12V 1A power adapter supplied with the

WNRT-630. Otherwise, the product may be damaged.

If you want to reset WNRT-630 to default settings, press

and hold the RESET button over 20 seconds and release.

And then wait for WNRT-630 restart.
