MANUAL
ZIPPER BAG
SCREW E #6-32 X5
SCREW C #6-32 X5
SCREW A #6-32 X4
SCREW B M3 X4
SCREW SLEEVE
HDD-TRAY
SCREW D #6-32 X5
USER INSTALLATION GUIDE
MOTHERBOARD STANDOFF
SECURE MOTHERBOARD, PSU and 3.5” HDD (For HDD bracket)
SECURE 2.5” HDD
2.5” OR 3.5” HDD
CONTAINS PARTS
SECURE 3.5” HDD
SECURE 3.5” HDD (For HDD tray)
SECURE STANDOFFS
PICTURE ITEM PURPOSE
2
Disassemble Chart
TOP COVER
12025 FAN X3
BOTTOM-FILTER
PSU (OPTION)
POWER BUTTON
USB 3.0 X2 + MIC + SPK
RESET BUTTON
ATX MB (OPTION)
3.5” & 2.5” HDD X4
(OPTION)
RIGHT-SIDE-PANEL
LEFT-SIDE-PANEL
