(1) CPU cooler height limitation

The TJ04-E can accommodate all standard size components and even some that are slightly out of spec.,

please refer to the following guidelines for component selection and future upgrade considerations.

Tip

CPU cooler height limit figure

Clearance 15mm Clearance 15mm

Maximum 168 mmMaximum 164 mm

E-

0JT

E-

0JT

The height limit is 168mm (164mm for TJ04-E with window side

panel) and there is 15mm of clearance around the motherboard.

Das Höhenlimit beträgt 168 mm (164 mm für das TJ04-E mit

einem Fenster in der Seitenwand) und es gibt 15 mm Freiraum

um das Mainboard herum.

La hauteur maximale est de 168mm (164mm pour TJ04-E avec

panneau latéral de type fenêtre) et il existe un dégagement de

15mm autour de la carte mère.

La altura límite es de 168mm (164mm para la TJ04-E sin el

panel lateral con ventana) y existe un espacio libre de 15mm

alrededor de la placa base.

L’altezza limite corrisponde a 168mm (164mm per il TJ04-E con

il pannello dotato di finestra trasparente) e vi sono 15mm di

tolleranza intorno alla scheda madre.

Ограничение по высоте составляет

168

мм (164 мм для TJ04-E

с окном в

боковой панели) и

мм

свободного

пространства

вокруг системной платы.

Cooler限高是168mm(開窗版本是164mm),Cooler

外緣允許超出主機板上邊界15mm

Cooler限高是168mm(开窗版本是164mm),Cooler

外缘允许超出主机板上边界15mm

高さ制限は168mm（ウインドウサイドパネル付きのTJ04-Eでは164mm）で、15mmの余裕がマザーボードのまわりにあります

높이 한계는 168mm(윈도우 측면 패널이 있는 TJ04-E의 경우 164mm) 이며 메인보드 주위에는 15mm 간격이 존재합니다.

Component Size Limitations
