SiENBE37-704 Model Selection
General Information 7
Connectable Indoor Unit
Note: FXDQ has following 2 Series, as shown below.
FXDQ-P, NAVE : with Drain Pump
BEV unit is required for FXUQ only.
Indoor unit capacity
Use the above tables to determine the capacities of indoor units to be connected. Make sure the
total capacity of indoor units connected to each outdoor unit is within the specified value (kW).
! The total capacity of connected indoor units must be within a range of 50 to 130% of the
rated capacity of the outdoor unit.
! In some models, it is not possible to connect the maximum number of connectable indoor
units. Select models so the total capacity of connected indoor units conforms to the
specification.
Type Model Name
Power
Supply
Roundflow Ceiling
Mounted Cassette
FXFQ 20P 25P 32P 40P 50P 63P 80P 100P 125P VE
600×600 4-Way Blow
Ceiling Mounted
Cassette
FXZQ 20M 25M 32M 40M 50M V1
2-Way Blow Ceiling
Mounted Cassette
FXCQ 20M 25M 32M 40M 50M 63M 80M 125M V3
Ceiling Mounted
Corner Cassette
FXKQ 25MA 32MA 40MA 63MA
VE
Slim Concealed Ceiling
Unit
FXDQ-
PVE
20P 25P 32P
FXDQ-
NAVE
40NA 50NA 63NA
Concealed Ceiling Unit
(Small)
FXDQ 20M 25M
V3
Concealed Ceiling Unit
FXSQ 20M 25M 32M 40M 50M 63M 80M 100M 125M
Concealed Ceiling Unit
(Large)
FXMQ 40MA 50MA 63MA 80MA
100MA 125MA 200MA 250MA
VE
Ceiling Suspended Unit
FXHQ 32MA 63MA
100MA
Wall Mounted Unit
FXAQ 20MA 25MA 32MA 40MA 50MA 63MA
Floor Standing Unit
FXLQ 20MA 25MA 32MA 40MA 50MA 63MA
Concealed Floor
Standing Unit
FXNQ 20MA 25MA 32MA 40MA 50MA 63MA
4-way blow ceiling
suspended unit
FXUQ
71MA
100MA 125MA
V1
Connection Unit for
FXUQ
BEVQ
71MA
100MA 125MA
VE
New refrigerant model code P20
type
P25
type
P32
type
P40
type
P50
type
P63
type
P80
type
P100
type
P125
type
P200
type
P250
type
Selecting model capacity 2.2
kW
2.8
kW
3.5
kW
4.5
kW
5.6
kW
7.0
kW
9.0
kW
11.2
kW
14.0
kW
22.4
kW
28.0
kW
Equivalent output 0.8HP 1HP
1.25HP
1.6HP 2.0HP 2.5HP 3.2HP 4HP 5HP 8HP 10HP
