:LULQJ'LDJUDPVIRU5HIHUHQFH 6L(1%(
$SSHQGL[
);$40$0$0$9(0$0$0$9(
3D034206D
INDOOR UNIT
A1P Printed circuit board
F1U Fuse (훾 3A, 250V)
HAP Light emitting diode
(service monitor-green)
M1F Motor (Indoor fan)
M1S Motor (Swing flap)
R1T Thermistor (Air)
R2T Thermistor (Coil liquid pipe)
R3T Thermistor (Coil gas pipe)
X1M Terminal block (Control)
X2M Terminal block (Power)
Y1E Electronic expansion valve
Power circuit
RECEIVER/DISPLAY UNIT (ATTACHED
TO INFRARED REMOTE CONTROL)
A2P Printed circuit board
A3P Printed circuit board
BS1 Push button (on/off)
H1P Light emitting diode (on-red)
H2P Light emitting diode
(Timer-green)
H3P Light emitting diode
(Filter sign-red)
H4P Light emitting diode
(Defrost-orange)
SS1 Selector switch (Main/Sub)
SS1 Selector switch
(Wireless address set)
1. : Terminal block : Connector
: Field wiring : connector
2. In case using central remote control, connect it to the unit in
accordance with the attached installation manual.
3. Symbols shows as follows:
RED:RED WHT:WHITE GRN:GREEN
PNK:PINK YLW:YELLOW ORG:ORANGE BLU:BLUE BLK:BLACK BRN:BROWN
4. :shows short circuit connector
5. :When connected the input wires from outside, forced
Note-5: Input from outside
Note-2: Transmission wiring
central remote control
Receiver/display unit
(Infrared remote control)
Power supply
Note-8
WIRED REMOTE CONTROL
R1R Thermistor (Air)
SS1 Selector switch (Main/sub)
CONNECTOR FOR OPTICAL PARTS
X15A Connector (Float switch)
X35A Connector (Group control adapter)
off or on/off control operation can be selected
by remote control.
In details, refer to the installation manual
attached the unit.
6. Remote control model varies according to the
combination system, confirm engineering data
and catalogs, etc. before connecting.
7. Confirm the method of setting the selector
switch (SS1, SS2) of wired remote control and
infrared remote control by installation manual
and engineering data
etc.
8. X24A is connected when the infrared remote
control kit is being used.
Wired remote
control
Note-8
Control box
(Indoor unit)
NOTES
Side
Front
