Line in

(audio in)

Connect a microphone to the network camera.

Line out

(audio out)

Connect a loud speaker to the network camera. This function is for voice

alerting and two-way audio.

DC-in Jack

The input power is 12VDC.

Note: ONLY use package power adapter supplied with the internet.

Otherwise, the product may be damaged.

RJ-45

Connects to 10Base-T Ethernet or 100Base-TX Fast Ethernet cabling. This

Ethernet port built N-Way protocol can detect or negotiate the transmission

speed of the network automatically. Please use Category 5 cable to connect

the Network Camera to a 100Mbps Fast Ethernet network switch or hub.

In the LAN socket, there are two LED embedded:

LAN LED (green color)

This LED will be flashing while network accessing via Ethernet.

Power LED (orange color)

This LED is used to indicate whether DC power is on or not. In addition, this

LED will be flashing while the wireless accessing of the Camera.

Reset Button

This button is used to restore the all factory default settings. Sometimes

restarting the device will make the system back to a normal state. However,

if the system still got problems after restart, user can restore the factory

default settings and install it again.

Restore the device:

a.) Press the button down continuously.

b.) Hold the button at least 5 seconds and release it. Then the

device has been restored to default settings and reboot again.

Note: Restoring the factory default setting will lose the all previous settings

included IP address forever. User needs to run the IPWizard program to

search the device and configure it to let the device work properly again.

DC-in jack for heater

There is another DC-in jack and this input power is 12VDC also. It supplies

the power to the heater inside the Camera.

Note that supply the power to the built-in heater with the power adapter

included in package.
