ActiveX Control: The plug-in ActiveX control supports a lot of functions by
clicking the left mouse button. Note that this feature only
supports on the ActiveX control within Microsoft® Internet
Explorer.
This function is detail setting for the camera that only available
for user logged into camera as administrator.
Item Action
Network
Configure Network settings such as Wireless,
DHCP, DDNS, 3GPP, PPPoE and UPnP.
Camera Adjust camera parameters.
System
Configure system information, date & time,
maintenance, and view system log file.
Video
Configure bit rate and frame rate of video
profiles.
Audio Configure audio parameters.
User Setup user name, password and login privilege.
E-Mail Setup E-Mail configuration.
FTP
This devise is a client site and configure
information to upload images to server.
Object
Detection
Setup Object detection.
Setting Menu:
Event
Schedule
Configure the schedule while event triggered.
Streaming Protocol: User can select proper streaming protocol according to
networking environment.
Language: The device could provide multiple languages to meet
customer’s requirement.
Video Information: Display video information including video format, resolution,
frame rate and bit rate.
Client Setting: Click this button to display the client extra control panel for
30
