1
Product Overview
Specifications
FORTRESS SERIES
FT01
Internal 3.5” x 7
Cooling System
Front 1 x 180mm intake fan, 700rpm, 18dBA
Top 1 x 180mm intake fan, 700rpm, 18dBA
Rear 1 x 120mm exhaust fan, 900rpm, 18dBA
Expansion Slot 7
Front I/O Port
USB2.0 x 2
IEEE1394 x 1
audio x 1
MIC x 1
Power Supply 1 x Optional standard PS2 (ATX)
Dimension 211 mm (W) x 486 mm (H) x 494.5 mm (D)
One CP05 included for single hot-swappable SATA
hard drive, additional CP05 can be purchased separately
SST-FT01B (Black)
SST-FT01S (Silver)
SST-FT01B-W (Black + window)
SST-FT01S-W (Silver + window)
Model No.
Material
3.0mm ~ 6.0mm uni-body aluminum outer frame and
aluminum body
Extra
Exposed
Motherboard ATX, Micro ATX
Driver Bay
5.25” x 5
