Daikin RXYN10AY1 [8/17] Specifications
![Daikin RXYN10AY1 [8/17] Specifications](/views2/1713894/page8/bg8.png)
English 4
2. SPECIFICATIONS
[Single unit]
3. WHAT TO DO BEFORE OPERATION
This operation manual is for the following system
with standard control. Before initiating operation,
contact your Daikin dealer for the operation that cor-
responds to your system type and mark.
If your installation has a customized control system,
ask your Daikin dealer for the operation that corre-
sponds to your system.
Outdoor units (Refer to figure 1)
•
Names and functions of parts (Refer to figure 1)
1. Outdoor unit
2. Indoor unit
3. BEV unit
4. Remote controller
5. Inlet air
6. Outlet air
7. Cool/Heat selector
(figure 1 shows system with Cool/Heat selector)
4. REMOTE CONTROLLER AND
COOL/HEAT SELECTOR: NAME
AND FUNCTION OF EACH
SWITCH AND DISPLAY
(Refer to figure 2 and 3)
1.
On/off button
Press the button and the system will start. Press
the button again and the system will stop.
2.
Operation lamp (red)
The lamp lights up during operation.
3.
Display
“”
(changeover under control)
It is impossible to changeover heat/cool with the
remote controller which display this icon.
4.
Display “” (ventilation/air cleaning)
This display shows that the ventilation unit are in
operation. (these are optional accessories)
5.
Display
“”
(set temperature)
This display shows the temperature you have set.
6.
Display
“”
“”
“”
“”
“”
(operation
mode)
This display shows the current operation mode.
7.
Display
“”
(programmed time)
This display shows the programmed time of the
system start or stop.
8.
Display
“”
(inspection/test operation)
When the inspection/test operation button is
pressed, the display shows the mode in which
the system actually is.
9.
Display
“”
(under centralized control)
When this display shows, the system is under
centralized control. (This is not a standard spec-
ification.)
10.
Display
“”
(fan speed)
This display shows the fan speed you have
selected.
11.
Display
“”
(time to clean air filter)
Refer to the operation manual of indoor unit.
12.
Display
“”
(defrost/hot start)
Refer to the chapter “Operation procedure -
Explanation of heating operation.”
13.
Timer mode start/stop button
Refer to the chapter “Operation procedure -
Programming start and stop of the system with
timer.”
14.
Timer on/off button
Refer to the chapter “Operation procedure -
Programming start and stop of the system with timer.”
15.
Inspection/test operation button
This button is only used by qualified service
persons for maintenance purposes.
16.
Programming time button
Use this button for setting the programming start
and/or stop time.
17.
Temperature setting button
Use this button for setting the desired temperature.
18.
Filter sign reset button
Refer to the operation manual of indoor unit.
19.
Fan speed control button
Press this button to select the fan speed of your
preference.
20.
Operation mode selector button
Press this button to select the operation mode of
your preference.
Model RXYN10AY1
Power supply
Phase
-
3N
~
Frequency
(Hz) 50
Voltage
(V) 380-415
Nominal cooling capacity
(kW) 28.0
Nominal heating capacity
(kW) 31.5
Dimensions H×W×D
(mm) 1680×635×765
Mass
(kg) 330
Refrigerant type
- R744
Refrigerant charge
(*1)
(kg) 7.2
Design pressure
High pressure side
(bar) 123
(MPa) 12.3
Low pressure side (bar) 95
(MPa) 9.5
Cool/Heat selector
Operation modes
Inverter series
heat pumps
RXYN
series ❏ yes ❏ no
C
TEST
01_EN_3P233622-1C.fm Page 4 Thursday, October 30, 2008 3:09 PM
