Wide Application Range
p. 12
Wide Range of Indoor Units
VRV air conditioning brings summer freshness and winter warmth to offices, hotels, department stores and
many other commercial premises. It enhances the indoor environment and creates a basis for increased
business prosperity and whatever the air conditioning requirement, a Daikin indoor unit will provide the
answer. VRV air conditioning can be supplied via 13 different indoor unit models in a total of 75 variations.
5
Cassette type unit
Concealed ceiling unit
Floor standing unit
