DAM602B51 256 indoor units per IPU
DAM602B52 128 indoor units per IPU
IM3.XX Up to 1,024 indoor units
KRP928A2S For connection to Split units
DTA102A52 For connection to R-407C/R-22 Sky Air units
DTA112B51 For connection to R-410A Sky Air units
DAM101A51 Outdoor temperature sensor
DEC101B51 Input contacts: 16 points
DEC102B51 Input contacts: 8 points; output contacts: 4 points
Intelligent Processing unit
Software
Interface adapters
DIII Ai
Digital input
Digital input/output
DESCRIPTION
REFERENCE COMMENTS
DMS502B51 64 units per Gateway
DAM411B51 Extension of 3 x DIII lines (3 x 64) indoor units
DAM412B51 For forced shutdown
KRP928A2S For connection to Split units
DTA102A52 For connection to R-407C/R-22 Sky Air units
DTA112B51 For connection to R-410A Sky Air units
BACnet Gateway
DIII board
Digital input/output
Interface adapters
DESCRIPTION
REFERENCE COMMENTS
• BMS: BUILDING MANAGEMENT SYSTEM
Contact / analog signal
Parallel interface - Basic unit
Temperature measurement units
Temperature setting units
Unification adapter for computerised control
Wiring adapter for electrical appendices (1)
Wiring adapter for electrical appendices (2)
External control adapter for outdoor unit
DIII-net expander adapter
Mounting kit
DPF201A51 enables ON/OFF command, operation and display of malfunction can be used in combination with up to 4 units.
DPF201A52 enables temperature measurement output for 4 groups; 0~5VDC.»
DPF201A53 enables temperature setting input for 16 groups; 0~5VDC.»
DCS302A52 used for combining of air conditioning control computer and central remote controller (ON/OFF, display)
KRP2A51
simultaneously controls air conditioning control computer and up to 64 groups of indoor units.
KRP2A52
KRP4A51-53 to control the group of indoor units collectively, which are connected by the transmission wiring of remote controller.
DTA104A51
cooling/heating mode change over, demand control and low noise control are available between the plural outdoor units.
DTA104A52
DTA109A51
a maximum of 10 outdoors or 128 indoors can be connected to 1 DTA109A51
a maximum of 8 DTA109A51 can be connected to DIII-net
KRP4A92 for easy installation of the DTA109A51
DESCRIPTION
REFERENCE COMMENTS
DMS504B51 Up to 64 units can be connected per DMS-IF
KRP928A2S For connection to Split units
DTA102A52 For connection to R-407C/R-22 Sky Air units
DTA112B51 For connection to R-410A Sky Air units
LONWORKS
®
networks compatible Gateway
Interface adapters
DESCRIPTION
REFERENCE COMMENTS
p. 75
