SUGO SG10

Redefining performance in small form factor computing

Material

Model

Motherboard

Drive Bay

Cooling System

Expansion Slot

Front I/O Port

Power Supply

Expansion Card

Dimension

Extra

*If you intend to utilize all hard drive slots, please remove all unused power supply cables.

These unused cables may cause problem with the installation. SSDs are highly recommended

in place of hard drives.

* Maximum length for PSU is 180mm, we recommend 160mm due to varying connector locations

on PSUs and the unique structure of SG10. We do not promise that all retail PSUs on the market

can be installed in the SG10. Please refer the guides provided in this manual to select your PSU.

Aluminum front panel, Steel body

SST-SG10B (black)

Micro ATX, Mini-DTX, Mini-ITX

Exposed

Internal

Rear

Top

Left

Right

USB 3.0 x 2 、audio x 1、MIC x 1

Optional standard PS2(ATX) up to 180mm*

Compatible up to 13.3” long, width restriction-5.70"

354mm (D) x 220mm (W) x 295mm (H), 23 liters

Support two Kensington locks

12.7mm/9.5mm slim optical x 1

3.5" x 2 * , 2.5” x4*

1 x 120mm 1200rpm 22dBA

180mm Air Penetrator 600/900/1200rpm, 17/25/34dBA

(backward compatible with 140mm)

1 x 120mm 1200rpm 22dBA(backward compatible with 92mm)

2*80/92mm fan slot

80mm fan slot
