3
Please remove the screws holding
the top cover with a screw driver,
then pull it toward the back to lift it
outward away from the chassis.
С помощью отвертки открутите
шурупы, удерживающие верхнюю
крышку, а затем снимите ее, сдвинув
назад и приподняв.
Bitte entfernen Sie die Schrauben der
oberen Abdeckung mit einem
Schraubenzieher und ziehen Sie die
Abdeckung nach hinten, weg von dem
Chassis.
Veuillez retirer les vis tenant le panneau
supérieur avec un tournevis, puis tirez-le
vers l’arrière afin de le soulever en
dehors du boîtier.
Por favor, quite los tornillos que
sujetan la cubierta superior con un
destornillador, luego tire de ella hacia
atrás para quitarla del chasis.
Rimuovere le viti del pannello
superiore con un cacciavite, spingerlo
verso la parte posteriore e sollevarlo
per asportarlo dal telaio.
상부 커버를 고정하고 있는 나사를
스크류 드라이버를 이용해 제거한 후,
뒤쪽으로 당겨 들어 올려, 케이스로
부터 제거합니다.
請以螺絲起子將鎖固上蓋的螺絲卸下，
並向後拉後提起以自機殼中取出。
请以螺丝起子将锁固上盖的螺丝卸下，
并向后拉后提起以自机壳中取出。
上部カバーを固定しているネジをドライバ
ーで外し、カバーを後方に引いてケースか
ら取り外します。
Install PSU into the case as shown. Установите блок SFX питания в
корпус, как показано на рисунке
Installieren Sie das SFX Netzteil wie
dargestellt im Gehäuse.
Installez l'SFX alimentation dans le
boîtier comme montré
Instale la SFX FA en la carcasa
como se muestra
Installare l’SFX alimentatore come
mostrato
그림에서와 같이 SFX PSU를 케이스에
장착합니다.
請依圖示將SFX電源放入機殼內。
请依图示将SFX电源放入机壳内。
図のように、ケースの中にSFX PSUを
インストールし。
