Scenario 7: H.323 VoIP Call: Register to Gatekeeper
Gateway 1 to Gateway 2 PLAR connection
Register Number List
GW1: 801
GW2: 901
H.323 Call (GK Mode)
Gateway#1
Gateway#2
801
901
901
801
WAN
GK
