NOTE
• Do not turn off power immediately after the
unit stops, but wait for at least 5 minutes.
• The system needs at least 5 minutes for the
residual operation of drain pump.
Turning the power off immediately will cause
water leak or trouble.
5-3 ADJUSTING THE AIR FLOW DIRECTION
(Refer to figure 6)
Press the air flow direction button to
select the air direction.
The air flow flap display swings as
shown on the right and the air flow
direction continuously varies. (Auto-
matic swing setting)
Press the air flow direction adjust button to
select the air direction of your choice.
The air flow flap display stops swing-
ing and the air flow direction is fixed.
(Fixed air flow direction setting)
MOVEMENT OF THE AIR FLOW FLAP
(Refer to figure 13)
For the following conditions, a micro computer con-
trols the air flow direction which may be different
from the display.
The air flow direction can be adjusted in one of the
following ways.
• The air flow flap itself adjusts its position.
• The air flow direction can be fixed by the user.
• Automatic
“”
and desired position
“”.
NOTE
• The movable limit of the flap is changeable.
Contact your Daikin dealer for details.
•
Avoid operating in the horizontal direction
“”
. It may cause dew or dust to settle on
the ceiling.
5-4 PROGRAMMING START AND STOP OF
THE SYSTEM WITH TIMER
(Refer to figure 9)
•
The timer is operated in the following two ways.
Programming the stop time “ ”. The sys-
tem stops operating after the set time has
elapsed.
Programming the start time “ ”. The sys-
tem starts operating after the set time has
elapsed.
• The timer can be programmed for a maxi-
mum of 72 hours.
• The start and the stop time can be simulta-
neously programmed.
Press the timer mode start/stop button several
times and select the mode on the display.
The display flashes.
• For setting the timer stop
“”
• For setting the timer start
“”
Press the programming time button and set
the time for stopping or starting the system.
Each time this button is pressed, the
time advances or goes backward by 1
hour.
Press the timer on/off button.
The timer setting procedure ends. The display
“”
or
“”
changes from flashing to
lighting.
NOTE
• When setting the timer off and on at the
same time, repeat the above procedure
(from
“”
to
“”
) once again.
• After the timer is programmed, the display
shows the remaining time.
• Press the timer on/off button once again to
cancel programming. The display vanishes.
For example: (Refer to figure 11)
When the timer is programmed to stop the sys-
tem after 3 hours and start the system after 4
hours, the system will stop after 3 hours and
start 1 hour later.
COOLING HEATING
• When starting operation.
• When the room temperature is
higher than the set temperature.
• At defrost operation.
• When operating continuously at horizontal air flow direction.
• When continuous operation with downward air flow is performed at the
time of cooling with a ceiling-suspended or a wall-mounted unit, the
microcomputer may control the flow direction, and then the remote con-
troller indication also will change.
1
2
1
2
3
1 3
