Planet PL-501 [5/8] Button definition

LED Denition

LED Status Description

Power On

Steady on indicate the Powerline device

connect to the power outlet

Ethernet

Blinking Blinking indicates the data are transferring

Steady on indicates the RJ-45 port has

correctly connected to the network card of

your PC or the Ethernet network

Data

Blinking

If the powerline device serving as a

STATION (STA), the LED indicator will

ash to indicated transmit or receive

powerline activity.

If the powerline device is serving as

a CCO (Central Coordinator), the LED

indicator will light steadily ON, even in the

presence of powerline activity.

Button Denition

Button Description

Reset Reset to factory default

Security

Press security button

during 1~3 seconds.

Join a another

HomePlugAV network

Press security button

more than 10 seconds

Set its security to

random value
