![Daikin RXYQ44PAY6 [20/33] The ntc national telecom corporation tower](/views2/1716144/page20/bg14.png)
36 37
The NTC (National Telecom Corporation) Tower
Khartoum, Sudan
9
PROJECT OUTLINE
235 units Cassette & Duct type × 473
Outside unit Indoor unit
EQUIPMENT
Location
Application
Number of floors
Project year
Total floor area
OFFICE
Khartoum, Sudan
Office
29F
2008
32,000m
2
Water cooled VRV system is installed because of following reasons
1. Suitable for high raised building
2. Easy installation and maintenance
3. Energy saving. Energy consumption can be monitored by intelligent Manager.
4. High outdoor temperature (50°C in summer).
PROJECT COMMENTARY
