VERIFY THE CONTENTS INSIDE PACKAGE BOX

The package should contain below items, if any item is missing or damaged, please contact the seller immediately

STEP 1: Connect the Power Adapter to VC-230. Check the PWR LED on the front panel is on accordingly

STEP 2: Connect the PC to LAN port. Check the LAN LED on the front panel is on accordingly

Power AdapterPhone CableCD-ROM Ethernet CableVC-230Quick Guide

And now you can manage the VC-230 by WEB UI. Please refer to the User’s Manual in CD-ROM for more information

APPLICATION

User name: “admin”

Password: “admin”

STEP 3: Open web browser, type the default IP address (http://192.168.1.1)

(DHCP Client or 192.168.1.2)

Power Adapter

FURTHER INFORMATION :

The above steps introduce simple installations and connections for VC-230. For further configurations of WAN, LAN, Firewall, Virtual

Server, DMZ, DDNS, and VDSL2 etc, please refer to the User’s Manual in the CD. If you have other questions, please contact the local

dealer where you purchased this product.

VDSL2

100Base-TX UTP

Telephone wire

LAN1

LAN2

VDSL2

Main office / PBX,

Telco CO, wire closet

VC-230

Phone

VDSL2

Internet

CPE

LAN1~4
