19
management mgmt <ipv4 address> [<netmask>] [<default_gateway>]
/*Set out-band management port IP setting*/
runningcfg save [<inbandBackupName>] [<generalBackupName>]
/*Save new setting to memory*/
After setting the in-band/out-band IP of the VC-2402, remember to connect its
Ethernet port MGMT to the Ethernet LAN. Then in the previous PC terminal screen,
type the following command to verify if the Ethernet connection between the
management station and the DSLAM is working.
ping <ipv4 address>
/*Ping to the management station to verify the connection is working*/
localhost:%congure
localhost:(conf)#management mgmt 172.16.77.35 255.255.255.0 172.16.77.177
localhost:(conf)#show management
GBE MGMT
---------------------------------------------------
MAC Address : 00:30:4f:71:36:71 00:30:4f:71:36:75
IP Address : 192.168.5.3 172.16.77.35
Network mask : 255.255.255.0 255.255.255.0
MTU : 1500 1500
MGMT default gateway : 172.16.77.177
Inband VLAN ID: No limit
Inband VLAN Priority: 0
localhost:(conf)#runningcfg save
Writing FLASH ...
Save success.
localhost:%ping 172.16.10.141
PING 172.16.10.141 (172.16.10.141): 56 data bytes
64 bytes from 172.16.10.141: icmp_seq=0 ttl=62 time=1.6 ms
64 bytes from 172.16.10.141: icmp_seq=1 ttl=62 time=1.0 ms
64 bytes from 172.16.10.141: icmp_seq=2 ttl=62 time=1.1 ms
64 bytes from 172.16.10.141: icmp_seq=3 ttl=62 time=1.0 ms
64 bytes from 172.16.10.141: icmp_seq=4 ttl=62 time=1.1 ms
--- 172.16.10.141 ping statistics ---
5 packets transmitted, 5 packets received, 0% packet loss
round-trip min/avg/max = 1.0/1.1/1.6 ms
localhost:%
Now you can access the VC-2402 via Telnet on port 23 (for using CLI) or Web GUI
byenteringitsIPaddressinyourbrowser’sURL/addresseld.
Besides CLI, you can also change the in-band/out-band management IP of the VC-
2402 in the Web GUI:
a. On the menu tree, click on
System ---> NT-Trunk Setup. The NT-Trunk Setup
page is displayed.
b. Enter new IP setting in the
GBE (In Band)sectionforin-bandIPconguration.
c. Enter new IP setting in the
MGMT (Out Band)sectionforout-bandIPcongu-
ration.
