Touch Package User Guide

4、 Multi-monitor page

This page function can be supported on the versions, Windows 2K,

XP, and Vista. The multi-monitorpage shows the system display

distribution in time. It also supports split display to fit some VGAcards.

User can right click to pull down the split display type to match your

VGA card (see Pic 5) andthen the page will show your settings.

User can click display area to show a matching program to link

the relation between touch device and display.

3、 Mouse page

The mouse page has four main items, report mode, right click

settings, double click settings, touch panel rotation（see Pic4）.

1. Report mode item： User can select drawing mode to continue

report all points that touch controller senses. Button mode only

report two points, first pen down and lift up points. Disable touch

will made touch device to not report any point, user must use

mouse to return the others to work properly.

2. Right click settings： Our touch solution can generate right click

in two ways.

I. Auto right click：If you pen down and no move for a while,

touch device will generate right click event automatically.

II.Manual right click：User launch the “Start manual right click”

button and touch solution will show a right click window at the

right-bottom corner. If user want to generate a right click, user

can hit this window once and then pen down and lift to have

a right click.

3. Double click settings： These two parameters, speed and area,

are used to change Windows OS parameters about generating

double click conditions. The bottom of these two shows the test

area and user can click to test the settings to feel your settings best.

4. Touch Panel Rotation： Cooperate with the picture of the display

to rotate, touching and accusing of the function needs and then

rotating too, very whirling angle is at present：0°（Default）、

90°、180°、270°。
