Contents

Index, Message, Introduction

Product Overview

Preparation for Assembly

Installing the Motherboard

Installing the Case Fan

Installing PSU & Other Accessories

Wiring Diagram

Installing Drives

Replacing the Drive Tray

Installing Expansion Card (Optional)

Replacing the Top Panel

A Message from the Streacom Team

Thank you for choosing Streacom! In a market dominated by generic and uninspired products, we are on a mission to break the mold, not only of design, but

materials and finish. This is a value that is not easily conveyed in an industry preoccupied with specs and numbers, so your choice shows an appreciation and

understanding of what makes our products different, and we sincerely thank you for that.

Every care has been taken to ensure that this product meets the highest quality and standards we have defined. If anything about this product falls short of

your expectations or you have any questions that are not covered in this user guide, please contact us online at www.streacom.com/contact. We respond to

every question received and your feedback is a critical part of our ongoing product development and refinement.

From everyone at Streacom, we hope that you enjoy using our product!

reproduced, stored in a retrieval system, or transmitted, in any form or in any means –

by electronic, mechanical, photocopying, recording or otherwise – without prior

written permission. All trademarks and registered trademarks in this publication are the

property of their respective owners. Streacom is a registered trademark.

Introduction to Assembling Your Case

It’s not rocket science, but Streacom cases can be a little challenging to assemble at first because of the non traditional design and the materials used. Passive cooled

cases have an added layer of complexity because of the heatpipe assembly/hardware requirements, so please take the time to read the user guide and become

familiar with the components and assembly procedure. Additional information is also available on our website ‘system build guide’ page, and of course from our

support staff.

Below is a quick explanation of the different screws used in the assembly, and how they will be referred to throughout the guide. Screws are defined by head type,

e.g. ‘countersunk’ and by thread/size e.g. M3x5, and will be labeled with all that information, e.g. CS-M3x5

Pan Head Screw ( )PH

Countersunk Screw ( )CS

Thin Cheese Head Screw ( )TC

PH-M3x5

5mm

3mm

M(Metric)

Also included in the kit.....

1 x Set of Fan Brackets (2pcs), Silicon Rubber Pads (Optical Only)

Tools you will need.....

Philips Screwdriver
