Daikin RZQ30PVJU Инструкция по монтажу онлайн
INSTALLATION MANUAL
English
Français
Español
SPLIT SYSTEM Air Conditioners
MODELS
RZQ18PVJU
RZQ24PVJU
RZQ30PVJU
Read these instructions carefully before installation.
Keep this manual in a handy place for future reference.
This manual should be left with the equipment owner.
Lire soigneusement ces instructions avant l’installation.
Conserver ce manuel à portée de main pour référence ultérieure.
Ce manuel doit être donné au propriétaire de l’équipement.
Lea cuidadosamente estas instrucciones antes de instalar.
Guarde este manual en un lugar a mano para leer en caso de tener alguna duda.
Este manual debe permanecer con el propietario del equipo.
00_CV_3PA60114-14U.indd 100_CV_3PA60114-14U.indd 1 1/26/2009 4:54:55 PM1/26/2009 4:54:55 PM
Содержание
- Installation manual 1
- Rzq18pvju rzq24pvju rzq30pvju 1
- Split system air conditioners 1
- Contents 2
- Safety considerations 2
- Safety considerations 1 2
- A outdoor temperature fdb b indoor temperature fwb c outdoor temperature fwb d indoor temperature fdb 4
- Accessories 2 4 4
- Confi rm that the following accessories are supplied 4
- Cooling heating 4
- Electrical specifi cations 2 3 4
- English 4
- For main components and function of the main components refer to the engineering data book 4
- In the table indicate the operating condition shown in the fi gure bottom left 4
- Install the indoor and outdoor units power supply wiring and transmission wiring at least 3 ft away from televisions or radios in order to prevent image interfer ence or noise depending on the radio waves a distance of 3 ft may not be enough to eliminate the noise dismantling of the unit treatment of the refrigerant oil and eventual other parts should be done in accordance with the relevant local and national regulations do not use the following tools that are used with con ventional refrigerants gauge manifold charge hose gas leak detector reverse fl ow check valve refrigerant charge base vacuum gauge refrigerant recovery equip ment if the conventional refrigerant and refrigerator oil are mixed in the r410a the refrigerant may deteriorated never perform outdoor unit piping connection work when it is raining 4
- Introduction 4
- Introduction 2 4
- Main components 2 5 4
- Range for continuous operation range for continuous operation range for pull down operation range for warming up operation range for operation 4
- Safety precaution 4
- Standard operation limit 2 1 4
- Technical specifi cations 2 2 4
- The pci data station is a class a product in a domestic environment this product may cause radio interference in which case the user may be required to take adequate mea sures 4
- The fi gures below assume following operating conditions for indoor and outdoor units equivalent pipe length 5 ft level difference ft 4
- Before installation 5
- Before installation 3 5
- Selection of installation loca 4 tion 5
- Selection of installation location 5
- Close the area under the frame so that the outlet air does 1 not bypass there only two outdoor units can be installed side by side 2 7
- Close the area under the frame so that the outlet air does not bypass there 7
- English 6 7
- The dimensional relationship between h l and a is as shown in the table below 7
- When an obstruction is present also in the upward area when one outdoor unit is installed individually 1 7
- When an obstruction on the air outlet side is higher than the outdoor unit there is no restriction in the height of obstruction on the air inlet side when the upward area is open when one outdoor unit is installed individually 1 7
- When only two outdoor units are installed side by 2 side 7
- When two or more outdoor units are installed side 2 by side 7
- Close the area under the frame so that the outlet air does 1 not bypass there only two outdoor units can be installed side by side 2 8
- Close the area under the frame so that the outlet air does not bypass there 8
- D when outdoor units are stacked when an obstruction is present on the air outlet 1 side 8
- English 8
- Only two outdoor units can be stacked 1 about 4 in is required as the drain piping size for the upper 2 outdoor unit close the area z gap between the upper outdoor unit and 3 the lower outdoor unit so that the outlet air does not by pass there 8
- The dimensional relationship between h l and a is as shown in the table below 8
- When an obstruction is present also in the upward area when one outdoor unit is installed individually 1 8
- When an obstruction on the air outlet side is lower than the outdoor unit there is no restriction in the height of obstruction on the air inlet side when the upward area is open when one outdoor unit is installed individually 1 8
- When only two outdoor units are installed side by 2 side 8
- When two or more outdoor units are installed side 2 by side 8
- Cautions on installation 9
- Cautions on installation 5 9
- Refrigerant piping work 9
- Refrigerant piping work 6 9
- Piping connection 6 3 10
- Protection of piping 6 2 10
- Selection of piping material 6 1 10
- Additional refrigerant charge 6 7 11
- Airtight test and vacuum drying 6 6 11
- Heat insulation of piping 6 5 11
- Refrigerant piping work procedure 6 4 11
- Electric wiring work 13
- Electric wiring work 7 13
- Caution 14
- Connection example of whole system wiring 7 1 14
- English 14
- Install an earth leakage circuit interrupter it is obliged to install an earth leakage circuit interrupter to prevent electric shock and fi re accident 14
- Let the power supply wiring with a conduit pass through one of the knockout holes on the front or side cover and let the transmission wiring with a conduit pass through another knockout hole for protection from uninsulated live parts thread the power supply wiring or the transmission wiring through the included insulating tube and secure it with the included clamp 14
- Never connect power supply wiring to the terminal block for 14
- Power supply wiring connection procedure 7 3 14
- Precautions when knocking out knock holes to punch the knockout hole hit it with a hammer after removing the knockout it is recommended that the edges should be painted to prevent rusting 14
- Remote controller wiring as this could damage the entire system 14
- Routing power supply wiring and transmission 7 2 wiring 14
- Use conduit for both the power supply wiring and transmis sion wiring outside the unit make sure to keep the wirings 5 inch away otherwise the outdoor unit may be affected by electrical noise external noise and malfunction or fail be sure to connect the power supply wiring to the terminal block and secure it as described in 7 3 power supply wiring connection procedure fix the wiring between the units in accordance with 7 4 transmission wiring connection procedure secure the wirings with the clamps accessory so that do not touch the piping make sure the wirings will not be pinched by the front panel and close the panel fi rmly route the conduit along the unit by using a elbow socket and so on to prevent it from being stepped on 14
- Warning 14
- Checks after completion of 8 work 15
- Checks after completion of work 15
- Transmission wiring connection procedure 7 4 15
- A crankcase heater is mounted for smooth startup make sure to turn on the power 6 hours before starting opera tion for supplying the power to the crankcase heater 16
- After turning on the power check the settings and led indicators on the pc board a1p in the outdoor unit through the opening of the insulating cover 16
- Caution 16
- Cautions before turning on the power 16
- English 16
- In the check operation the status of the outdoor unit is checked and incorrect wiring is checked for 16
- Make sure to close the outer panel before leaving the outdoor unit in the power on status to avoid injury always make sure that the circuit breaker on the power supply panel of the installation is switched off before doing any work 16
- Make sure to open the stop valve after fi nishing the piping work operating the air conditioner with the stop valve shut may damage the compressor 16
- Make sure to perform the check operation after installation if the air conditioner is operated using the indoor remote controller without performing the check operation the mal function code u3 is displayed in the indoor remote control ler and normal operation is disabled 16
- Piping size and heat insulation 5 refer to 6 1 selection of piping material 6 5 heat insulation of the piping check of stop valve 6 confi rm that the stop valve is open on both the liquid line and gas line record of amount of additional refrigerant 7 record the amount on the label sticked on the back of the front panel measurement of insulation in main power circuit 8 use the megatester for 500 v do not use any megatester for low voltage electric circuits except 230 v wiring between the outdoor unit and the indoor unit 16
- Power on and check operation 9 1 16
- Put the insulating cover securely onto the electric parts box 16
- Test operation procedure 16
- Test operation procedure 9 16
- Warning 16
- After fi nishing the check operation operate the air condi tioner normally heating is not available if the outside air temperature is 75 f or more refer to the operation manual supplied together with the unit confi rm that the indoor and outdoor units are operating normally if a knocking sound is heard in the liquid compression of the compressor stop the air conditioner immediately and energize the crankcase heater for a suffi cient period of time then start the operation again run the indoor unit one by one in turn and confi rm that the corresponding outdoor unit is running check to see if cold or hot air is coming out of the indoor unit press the fan direction button and fan speed control button on the remote controller to see if the fan is operating nor mally 17
- Check a malfunction code in the remote controller connected to the indoor unit 17
- Checks in normal operation 9 2 17
- English 16 17
- If the air conditioner is started within about 12 minutes after the power of the indoor outdoor unit is turned on the h2p indicator lights and the compressor does not run confi rm that the led status is as shown in the table in 2 in 9 1 power on and check operation before starting the air conditioner the air conditioner may require about 10 minutes maximum until it can start the compressor after start of operation this period of time is required to homogenize the refrigerant status and does not indicate any failure the check operation does not provide any means of check ing the indoor units individually for that purpose perform the normal operation using the remote controller after fi nish ing the check operation the check operation is not available in any other mode such as the recovery mode before running a check on the unit changing the indoor remote controller settings might cause the error code uf to be displayed and prevent a proper check to be run 17
- Once stopped the compressor will not start for about 5 minutes even if the on off button on the remote con troller is pressed when the system operation is stopped by the remote con trol the outdoor units may continue to operate for a further 3 minutes if the system has not undergone the check operation by the test operation button since it was fi rst installed a malfunc tion code u3 is displayed in this case perform the check operation by referring to 9 1 power on and check operation 17
- When a malfunction code is displayed in the remote controller 17
- Caution for refrigerant leaks 18
- Caution for refrigerant leaks 10 18
