2.3 Max. Input AC Current
3.1 Normal Operation Output
3. Output characteristics
Max. Input Current
ST75F-PT
ST75F-PT
ST65F-PT
ST55F-PT
2.4 Inrush Current
The power supply must meet inrush requirements for any rated AC voltage, during turn on at any phase
of AC voltage, during a single cycle AC dropout condition, during repetitive ON/OFF cycling of AC, and
over the specified temperature range. The peak inrush current shall be less than the ratings of its critical
components (including input fuse, bulk rectifiers, and surge limiting device).
2.5 Efficiency
ST75G-PT, ST65F-PT, ST55F-PT provides an efficiency of 89% minimum when measured at full load under
115V/60Hz and 230V/50Hz condition.
Maximum continuous total DC output power should not exceed750W.
Maximum continuous combined load on +3.3VDC and +5VDC outputs shall not exceed 120W.
Maximum combined load on +12V outputs shall not exceed 750W.
NOTE:
Noise test should be measured with 20 MHz bandwidth frequency oscilloscope. The output terminal shall
add a tantalum capacitor of 10uF in parallel with a ceramic capacitor of 0.1uF.
10A
Measuring Range
90 - 264 Vrms
Max. Input Current
10A
Measuring Range
90 - 264 Vrms
Max. Input Current
8A
Measuring Range
90 - 264 Vrms
Output Voltage
1. +5V
2. +12V
4. –12V
5. +5Vs
6. +3.3V
Load MIN
0.2A
0.0A
0.0A
0.0A
0.0A
Range MAX
22A
62.5A
0.3A
3.0A
22.0A
Regulation
±3%
±3%
±10%
±5%
±3%
Ripple & Noise P-P Max.
50mV
120mV
120mV
50mV
50mV
