Daikin VAM650J7VEB Технические данные онлайн
Ventilation
Technical Data
VAM-J
> VAM350J7VEB
> VAM500J7VEB
> VAM650J7VEB
> VAM800J7VEB
> VAM1000J7VEB
> VAM1500J7VEB
> VAM2000J7VEB
Содержание
- Technical data 1
- Ventilation 1
- Ventilation technical data 1
- Centre of gravit 3
- Dimensional drawing 3
- Electrical specifications 3
- Exchange efficienc 3
- Fan characteristic 3
- Feature 3
- Filter installation method 3
- Installatio 3
- Installation method 3
- Option 3
- Sound dat 3
- Sound power spectrum 3
- Sound pressure spectrum 3
- Specification 3
- Table of contents vam j 3
- Technical specifications 3
- Wiring diagram 3
- Wiring diagrams single phase 3
- Can be used as stand alone or integrated in the sky air or vrv system 4
- Can operate in over and under pressure 4
- Energy saving ventilation using indoor heating cooling and moisture recovery 4
- Features 4
- Filter change indication based on actual filter contamination 4
- Free cooling possible when outdoor temperature is below indoor temperature eg during nighttime 4
- Ideal solution for shops restaurants or offices requiring maximum floor space for furniture decorations and fittings 4
- Indoor unit vam j 4
- No drain piping needed 4
- Optional medium and fine dust filters epm10 70 m6 epm1 55 f7 epm1 70 f8 to meet customer request or legislation 4
- Prevent energy losses from over ventilation while improving indoor air quality with optional co2 sensor 4
- Reduced energy consumption thanks to specially developed dc fan motor 4
- Shorter installation time thanks to easy adjustment of nominal air flow rate so less need for dampers compared with traditional installations 4
- Specially developed heat exchange element with high efficiency paper hep 4
- Total fresh air solution with optional electrical heater 4
- Ventilation vam j 2 4
- Ventilation with heat recovery as standard 4
- Wide range of units air flow rate from 350 up to 2 000 m³ h 4
- 1 technical specifications 5
- Specifications 5
- 1 technical specifications 6
- 2 electrical specifications 6
- Indoor unit vam j 6
- Specifications 6
- Ventilation vam j 4 6
- 1 options 7
- Options 7
- Exchange efficiency 8
- Indoor unit vam j 8
- Ventilation vam j 6 8
- 1 exchange efficiency 9
- Exchange efficiency 9
- 1 dimensional drawings 10
- Air filter 10
- Ceiling hook 10
- Damper panel 10
- Dimensional drawings 10
- Exhaust air fan 4 12 x 40 mm oblong hole 10
- Heat exchanger 10
- Inspection hole 10
- Maintenance cover 10
- Maintenance space for the air filters heat exchangers and fans 10
- Sealing material 10
- Supply air fan 10
- Switch box 10
- Ceiling hook 4 12 x 40 mm oblong hole damper panel 11
- Dimensional drawings 11
- Exhaust air 11
- Exhaust air fan 11
- Exhaust air to outdoors 11
- Fresh outdoor air 11
- Heat exchanger 11
- Inspection hole 11
- Maintenance cover 11
- Maintenance space for the air filters heat exchangers and fans 11
- Outdoor air 11
- Return air from room 11
- Room air 11
- Sealing material 11
- Supply air 11
- Supply air fan 11
- Supply air to room 11
- Switch box 11
- Switch box air filter 11
- 1 dimensional drawings 12
- Dimensional drawings 12
- To allow for the inspection of the air filters heat exchangers and fans be sure to provide the inspection hole 12
- 1 centre of gravity 13
- Centre of gravity 13
- 1 centre of gravity 14
- Centre of gravity 14
- 1 centre of gravity 15
- Centre of gravity 15
- 1 centre of gravity 16
- Centre of gravity 16
- 1 wiring diagrams single phase 17
- Wiring diagrams 17
- 1 wiring diagrams single phase 18
- Control box 18
- D112850 18
- Indoor 18
- Vam350 650j 18
- Warning 18
- Wired remote control 18
- Wiring diagrams 18
- X14a x35a 18
- X2m x1m 18
- X35a x33a 18
- 1 wiring diagrams single phase 19
- Control box 19
- K1r z1f 19
- Warning 19
- Wiring diagrams 19
- X14a x35a 19
- X2m x1m x33a 19
- X35a x33a 19
- 1 sound power spectrum 20
- Indoor unit vam j 20
- Sound data 20
- Ventilation vam j 18 20
- 1 sound power spectrum 21
- Dba a weighted sound power level a scale according to iec reference acoustic intensity 0db 10e 6μw m² measured according to iso 3744 21
- Fan speed 21
- Sound data 21
- Ultra high 21
- 1 sound power spectrum 22
- 125 250 500 1000 2000 4000 8000 dba 22
- Dba a weighted sound power level a scale according to iec reference acoustic intensity 0db 10e 6μw m² measured according to iso 3744 22
- Fan speed 22
- Octave band centre frequency hz 22
- Sound data 22
- Sound power level db 22
- Ultra high 22
- 1 sound power spectrum 23
- Sound data 23
- 2 sound pressure spectrum 24
- D113499 24
- D113500 24
- Sound data 24
- Vam350j 24
- Vam500j 24
- 2 sound pressure spectrum 25
- 5 125 250 500 1000 2000 4000 8000 dba 25
- Nr5 nr10 nr15 25
- Octave band centre frequency hz 25
- Sound data 25
- Sound pressure level db 25
- 2 sound pressure spectrum 26
- D112845 26
- D112846 26
- Sound data 26
- Vam1000j 26
- Vam1500j 26
- 2 sound pressure spectrum 27
- Sound data 27
- 1 fan characteristics 28
- Fan characteristics 28
- 1 fan characteristics 29
- Fan characteristics 29
- 1 fan characteristics 30
- Air flow rate m³ h 30
- Duct length 30
- External static pressure pa 30
- Fan characteristics 30
- H8 h15 uh1 uh8 30
- High speed 30
- Indoor unit vam j 30
- Legend 30
- Low speed 30
- Low speed high speed 30
- Low speed lower limit low speed factory setting low speed upper limit high speed lower limit high speed factory setting high speed upper limit ultra high speed lower limit ultra high speed factory setting ultra high speed upper limit 30
- Measured according to jis b 8628 2003 30
- Ra room air 30
- Sa supply air 30
- The fan curves are determined with 1 3 of the esp on the outdoor side ea oa and 2 3 of the esp on the indoor side ra sa ea exhaust air oa outdoor air 30
- Ultra high speed 30
- Ventilation vam j 28 30
- Xø250 30m 30
- 1 fan characteristics 31
- Air flow rate m³ h 31
- Air flow rate m³ h air flow rate m³ h 31
- Duct length 31
- External static pressure pa 31
- External static pressure pa external static pressure pa 31
- Fan characteristics 31
- H1 high speed lower limit 31
- H8 high speed factory setting h15 high speed upper limit uh1 ultra high speed lower limit uh8 ultra high speed factory setting uh15 ultra high speed upper limit 31
- High speed 31
- L1 low speed lower limit l8 low speed factory setting 31
- L15 low speed upper limit 31
- L8 l1 l15 31
- Low speed 31
- Measured according to jis b 8628 2003 31
- The fan curves are determined with 1 3 of the esp on the outdoor side ea oa and 2 3 of the esp on the indoor side ra sa ea exhaust air oa outdoor air ra room air sa supply air 31
- Ultra high speed 31
- Xø250 31
- 1 installation method 32
- Installation 32
- 1 installation method 33
- Installation 33
- 2 filter installation method 34
- D112840 34
- Installation 34
- Daikin europe n v naamloze vennootschap zandvoordestraat 300 b 8400 oostende belgium www daikin eu be 0412 120 336 rpr oostende 35
