STRIDER PLUS SERIES
09
14.1 Physical Dimension
150 mm (W) × 86 mm (H) × 140mm (D)
14.2 Connectors
14. Mechanical Requirements
M/B 24PIN connector
The product shall meet requirement for EN61000-3-2 & EN61000-3-3 :1995
standard of class D, test at 230Vac 50Hz.
12. Harmonics
The power supply with active power factor correction, and meet the EN61000-3-2
standards, The power factor is greater than 0.9 at 230V/50Hz, Max. load.
13.Power Factor
10
Yellow
Black
Black
Red
Signal
+12V
COM
COM
+5VDC
Pin
1
2
3
4
Pin
1
2
3
4
Signal
+5VDC
COM
COM
+12V
Red
Black
Black
Yellow
4PIN peripheral connector (HDD) 4PIN floppy connector (FDD)
ATX 12V 4PIN (4+4PIN EPS 12V in split mode)
Signal
GND
GND
Pin
1
2
Pin
3
4
Signal
+12V
+12V
EPS 12V 8PIN connector
Yellow
Yellow
Yellow
Yellow
Signal
+12V
+12V
+12V
+12V
Pin
5
6
7
8
Pin
1
2
3
4
Signal
COM
COM
COM
COM
Black
Black
Black
Black
SATA connector
Signal Pin
Orange
+3.3V 5
Black
COM 4
Red
+5V 3
Black
COM 2
Yellow
+12V 1
