SilverStone SX600-G [9/12] Environment
![SilverStone SX600-G [9/12] Environment](/views2/1719557/page9/bg9.png)
06
4.3 Hold up time
When the power loss its input power, it shall maintain 12ms at 75% load in regulation limit at nominal input
voltage. (AC:115V/60Hz or 230V/50Hz)
4.4 Test conditions
Test
1
3
Start Voltage
[Vac]
230
100
End
Voltage
[Vac]
0
0
Duration
[cycles / ms]
0.5 / 10ms
0.5 / 8.33ms
Load
75% Load
75%Load
Frequency
[Hz]
50
60
5.1 Operation
Temperature
Relative Humidity
0 to 40 C
to 85%,on-condensing
5.2 Shipping and Storage
Temperature
Relative Humidity
-20 to 60 C
to 95%,non-condensing
5.3 Altitude
Operating
Storage
10,000FT max.
50,000FT max.
5. ENVIRONMENT
