SilverStone TX700 Gold Инструкция по эксплуатации онлайн
TX500 / TX700
TFX SERIES
The reference TFX power supply
500W / 700W continuous power output at 50°C operating temperature rated for 24/7 operation
High efficiency with 80 PLUS Gold certification
Silent running 80mm fan with 18 dBA minimum
Multiple protection circuitry
Single PCI-E 6+2pin connectors support
Содержание
- Tfx series 1
- The reference tfx power supply 1
- Tx500 tx700 1
- Electrical 2
- G1123 tx500 p313 pkg manual p1 v1 2
- Specification 2
- Switching power supply with active pfc 80plus gold 2
- Tfx form factor sst tx500 g 500w sst tx700 g 700w 2
- Ac input 3
- Dc output 3
- Dc output load distributions 3
- G1123 tx500 p313 pkg manual p2 v1 3
- Note 12v at 0 a maximum requires 12v rail to be loaded at 2a minimum 3
- Table 1 lists ac input voltage and frequency range for continuous operation the power supply is capable of supplying full rated output power over the input voltage ranges as specified 3
- The dc output voltages remain within the regulation ranges shown in table 2 when measured the at load end of the output connectors under all ac line o p loads and environmental conditions the voltage regulation will be maintained under continuous operation for a period of time equal to the mtbf specified in section 5 at any steady state temperature and operating conditions specified in section 3 3
- The inrush current is less than 130a under the conditions of 230vrms input and 25 oc ambient cold start the inrush current is limited to the extent that no damage will be done to the power supply under any specified line load and temperature conditions the inrush current will not cause external protection devices fuses to trip the leakage current of the power supply module is less than 3 ma measured at 230vac input the repetitive on off cycling of ac input voltage will not damage the power supply the primary fuse is installed for input over current protection and meet product safety requirement 3
- The table 3 defines the power supply typical output load distribution 3
- Dc output efficiency 4
- G1123 tx500 p313 pkg manual p3 v1 4
- In order to meet 2013 erp requirements the following guidance must be met for the 5vsb efficiency at 230vac 4
- Peak dc output power 17 seconds maximum one occurrence maximum per minute 115vac 60hz 230vac 50hz 4
- Table 3 dc output load distribution 4
- Table 4 the power supply typical output load distribution 4
- Table 5 the power supply typical output load distribution 4
- The power supply efficiency is 87 minimum measured at 20 efficiency is 90 minimum measured at 50 efficiency is 87 minimum measured at 100 which is 115vrms conditions shown in table 4 4
- 12v 5v 3 v 12v 5vsb unit 5
- 50 50 120 50 mv p p 5
- Dc output ripple noise 5
- Dc output transient response 5
- Dc output voltage hold up time 5
- G1123 tx500 p313 pkg manual p4 v1 5
- Max ripple noise 5
- Table 6 dc output ripple noise 5
- The output ripple noise specifications listed in table 6 will meet throughout the load ranges as specified in section 2 and the nominal line input voltage conditions as specified in section 2 ripple noise is defined as periodic of random signals over a frequency band of 10hz to 20mhz measurements should be made with an oscilloscope with 20mhz bandwidth adding a 10uf electrolytic capacitor and a 0 uf ceramic capacitor across output terminal during ripple noise measurement 5
- The output voltages will remain within the regulation limits specified in table 2 the load changing repetition rate is 50hz to 10khz and the transient load slew rate 1 a us the maximum step load size and output capacitive loading are specified as followings in table 7 5
- The power supply will maintain outputs in regulation per section 2 despite a loss of input power at the nominal range of ac input and at 80 of maximum continuous output load as applicable for a minimum of 10 msec 5
- Voltage limits 5
- G1123 tx500 p313 pkg manual p5 v1 6
- Pwr_ok is a power good signal it will be asserted high by the power supply to indicate that the 5v output is above the under voltage threshold listed in table 2 of section 2 pwr_ok will be de asserted to a low state when 5v output voltage falls below under voltage threshold or when ac power has been removed for a time sufficiently such that power supply operation cannot work normally the electrical and timing characteristics of the pwr_ok signal are given in table 8 and in figure 1 6
- Pwr_ok power good signal 6
- Timing housekeeping control 6
- G1123 tx500 p313 pkg manual p6 v1 7
- G1123 tx500 p313 pkg manual p7 v1 8
- Environmental 9
- G1123 tx500 p313 pkg manual p8 v1 9
- Electromagnetic compatibility 10
- G1123 tx500 p313 pkg manual p9 v1 10
- G1123 tx500 p313 pkg manual p10 v1 11
- Mechanical 11
- Power supply connector overuse definition 11
- Reliability 11
- Definición de uso excesivo del conector de la fuente de alimentación 12
- Definizione di uso eccessivo del connettore di alimentazione 12
- Définition de l utilisation excessive du connecteur d alimentation électrique 12
- G1123 tx500 p313 pkg manual p11 v1 12
- Power supply connector overuse definition 12
- G1123 tx500 p313 pkg manual p12 v1 13
- G1123 tx500 p313 pkg manual p13 v1 14
- Openings that do not exceed 1mm in width regardless of length 14
- Openings that do not exceed 5mm in any dimension 14
- 寬度小於1mm 則長度不限 14
- 對角線不大於5mm 14
- 直徑不大於5mm 14
- G1123 tx500 p313 pkg manual p14 v1 15
- G1123 tx500 p313 pkg manual cover v1 16
