BRCHW

FXZA-A

Indoor unit FXZA 15A 20A 25A 32A 40A 50A

Cooling capacity Total capacity At high fan speed kW 1.70 2.20 2.80 3.60 4.50 5.60

Heating capacity Total capacity At high fan speed kW 1.90 2.50 3.20 4.00 5.00 6.30

Power input - 50Hz Cooling At high fan speed kW 0.043 0.045 0.059 0.092

Heating At high fan speed kW 0.043 0.045 0.059 0.092

Dimensions Unit HeightxWidthxDepth mm 260x575x575

Weight Unit kg 15.5 16.5 18.5

Casing Material Galvanised steel plate

Decoration panel Model BYFQ60C2W1W

Colour White (N9.5)

Dimensions HeightxWidthxDepth mm 46x620x620

Weight kg 2.8

Decoration panel 2 Model BYFQ60C2W1S

Colour SILVER

Dimensions HeightxWidthxDepth mm 46x620x620

Weight kg 2.8

Decoration panel 3 Model BYFQ60B2W1

Colour White (RAL9010)

Dimensions HeightxWidthxDepth mm 55x700x700

Weight kg 2.7

Decoration panel 4 Model BYFQ60B3W1

Colour WHITE (RAL9010)

Dimensions HeightxWidthxDepth mm 55x700x700

Weight kg 2.7

Fan Air ow rate -

50Hz

Cooling

At high fan speed m³/min 8.5 8.7 9.0 10.0 11.5 14.0

Heating

At high fan speed m³/min 8.5 8.7 9.0 10.0 11.5 14.0

Air lter Type Resin net

Sound power level Cooling At high fan speed dBA 49 50 51 54 60

Sound pressure

level

Cooling Low/medium/high fan speed dBA 25.5/28.0/31.5 25.5/29.5/32.0 25.5/30.0/33.0 26.0/30.0/33.5 28.0/32.0/37.0 33.0/40.0/43.0

Heating Low/medium/high fan speed dBA 25.5/28.0/31.5 25.5/29.5/32.0 25.5/30.0/33.0 26.0/30.0/33.5 28.0/32.0/37.0 33.0/40.0/43.0

Refrigerant Type/GWP R-32 / 675

Piping connections Liquid OD mm 6.35

Gas OD mm 9.52 12.7

Drain VP20 (I.D. 20/O.D. 26)

Power supply Phase/Frequency/Voltage Hz/V 1~/50/60/220-240/220

Current - 50Hz Maximum fuse amps (MFA) A 6

Control systems Infrared remote control BRC7EB530W (standard panel) / BRC7F530W (white panel) / BRC7F530S (grey panel) (1)

Wired remote control BRC1H52W/S/K

Dimensions do not include control box

() Must be combined with Madoka wired remote controller.

Fully at cassette

Unique design in the market that

integrates fully at into the ceiling

› Optimised design for R- refrigerant

› Fully at integration in standard architectural ceiling tiles, leaving

only mm

› Remarkable blend of iconic design and engineering excellence

with an elegant nish in white or a combination of silver

and white

› Two optional intelligent sensors improve energy eciency

and comfort

›  class unit especially developed for small or well-insulated

rooms, such as hotel bedrooms, small oces, etc.

› Individual louver control: exibility to suit every room layout

without changing the location of the unit!

›

Optional fresh air intake

› Standard drain pump with mm lift increases exibility and

installation speed

NEW

FXZA-A

Access all technical information on FXZA-A

my.daikin.eu or click here

BRPC

NEW
