PANEL DESCRIPTION

USER SET MODE KEY

➥ Push and hold to enter user set mode.

• During user set mode, push this key to select an item, and

change the value or condition using push [CH Up]/[CH Down].

➥ Push and hold this key again to exit user set mode.

User set mode is also available via the ‘Power ON function.’

Refer to p. 14 also.

OPT 1/2/3 KEYS

Push to control the output signal level from the optional unit

connector.

DIGITAL BUTTON KEY (BIIS operation only)

➥ Push to select the call ID list, transmit message and stand-

by condition. Toggles between queue channel and

received message record indication after queue channel is

selected.

➥ Push and hold to select queue channel indication.

✩ STATUS UP/DOWN KEYS (BIIS operation only)

➥ While in the standby condition, push (or rotate)* to display

the transmit status indication and select a status number.

➥ When a received SDM is displayed, push (or rotate)* to

cancel the automatic scroll and scroll the message manu-

ally.

➥ When an SDM that contains more than 12 characters is

displayed, push (or rotate)* to scroll the message manually.

*Rotate when this function is assigned to [DIAL].

TONE/NAC CH SELECT KEY

(LMR (P25 Conventional) operation only)

➥ While in the analog mode operation, push to select the

continuous tone channel using [CH Up] or [CH Down] to

change the tone frequency/code setting.

➥ While in the digital mode operation, push to select the NAC

channel using [CH Up] or [CH Down] to change the NAC

code setting.

➥ While in the mixed (digital and analog) mode operation,

push to select the continuous tone channel using [CH Up]

or [CH Down] to change the tone frequency/code setting.

Then push this key to enter the setting. After that, the NAC

channel selection screen appears. Select the NAC chan-

nel using [CH Up] or [CH Down] to change the NAC code

setting. Then push this key to enter the setting.
