05
4. Protection
Protection circuits inside the power supply shall cause only the power supply's main
outputs to shutdown. If the power supply latches off due to a protection circuit tripping,
either a AC cycle OFF for 15 sec, or PSON# cycle HIGH for 1 sec must be able to restart
the power supply.
4-1. Over Current Protection
This power supply shall have current limit to prevent the +5V, +3.3V, and +12V
outputs from exceeding the values shown in table 14. The current limit shall not trip
under maximum continuous load or peak loading as described in Table 5. The power
supply shall latch off if the current exceeds the limit. The latch shall be cleared by
toggling the PSON# signal or by cycling the AC power. The power supply shall not
be damaged from repeated power cycling in this condition. The -12V and +5VSB
outputs shall be shorted circuit protected so that no damage can occur to the power
supply.
Table 14 -Over Current protection
4-2. Over Voltage Protection
The power supply shall shut down in a latch off mode when the output voltage
exceeds the over voltagelimit shown in Table 4.
Table 15 -Over Voltage protection.
4-3. Short Circuit Protection
The power supply shall shut down in a latch off mode when the output voltage is
short circuit.
5. Environmental Requirements
5-1. Temperature
Voltage
+5V
+3.3V
+12V
Minimum
110%
110%
110%
Maximum
160%
160%
160%
Shutdown Mode
Latch Off
Latch Off
Latch Off
Voltage
+5V
+3.3V
+12V
5VSB
Minimum
+5.7V
+3.9V
+13.3V
5.7
Maximum
+6.5V
+4.5V
+14.5V
6.5
Shutdown Mode
Latch Off
Latch Off
Latch Off
Auto recovery
Operating Temperature Range:
0℃ ~ 50℃ (32℉~ 122℉)
Non-Operating Temperature Range: -40℃ ~ 70℃ (-40℉~ 158℉)
