SilverStone SST-OP1000-P [3/12] Dc output specification

ŐőĲıııĮņ

+5V

30A

1.0A

180W

980W

28A 80A 0.5A 4A

0A 0.1A

+3.3V

0A 3A

960W

20W

+12V(Single Rail) -12V +5VSB

Output Voltage

Max.Load

Max.Combined

Total Output

Min.Load

2.3 Input Power Factor Correction ( Active PFC)

2.4 Input Current Harmonics

When the power supply is operated in 90-264Vac of Sec. 2.1, the input harmonic current

drawn on the power line shall not exceed the limits set by EN61000-3-2 class “D” standards.

The power supply shall incorporate universal power input with active power factor correction.

2.5 AC Line Dropout

An AC line dropout of 15mS or less shall not cause any tripping of control signals or

protection circuits.If the AC dropout lasts longer than 15mS the power supply should

recover and meet all turn on requirements. The power supply shall meet the regulation

requirement over all rated AC voltages, frequencies, and output loading conditions. Any

dropout of the AC line shall not cause damage to the power supply. An AC line dropout is

defined as a drop in AC line to 0VAC at any phase of the AC line for any length of time.

3. DC Output Specification

The following tables define two power and current rating. The power supply shall meet

both static and dynamic voltage regulation requirements for minimum load condition.

3.1 Output Current / Loading

Single rail for +12V

Note 1: Maximum continuous total DC output power should not exceed 1000 W.

3.2 DC Voltage Regulation, Ripple and Noise

The power supply output voltages must stay within the following voltage limits when

operating at steady state and dynamic loading conditions. All outputs are measured

with reference to the return remote sense (ReturnS) signal. The +5V,+3.3V, +12V, -12V

and +5VSB outputs are measure at the power supply connectors references to ReturnS.

The +5V and +3.3V is measured at its remote sense signal (+5VS, +3.3VS) located at

the signal connector.
