04
Item
Tvout rise
Tvout on
Tvout off
Description
Output voltage rise time from each main output.(+5Vsb < 70mS)
All main output must be within regulation of each other within this time.
All main output must leave regulation within this time
MIN
5
MAX
70
50
400
Units
mS
mS
mS
Description
Delay from AC being applied to +5VSB being within regulation.
Delay from AC being applied to all output voltages being within
regulation.
All main output voltage stay within regulation after loss of AC
Delay from loss of AC deassertion of PWOK.
Delay from PSON# active to output voltage within regulation
limits.
Delay from PSON# deactive to PWOK being deasserted.
Delay from output voltage within regulation limits to PWOK
asserted at turn on.
Delay from PWOK deasserted to output voltages (+5V, +3.3V,
+12V) dropping out of regulation limits.
Duration of PWOK being in the deasserted state during an off/on
cycle using AC or the PSON# signal. .
Delay from +5VSB being in regulation to O/Ps being in regulation
at AC turn on.
Item
Tsb on-delay
Tac on-delay
Tvout holdup
Tpwok holdup
Tpson on delay
Tpson pwok
Tpwok on
Tpwok off
Tpwok low
Tsb vout
MIN
18
17
5
100
1
100
50
MAX
1500
2500
400
50
500
1000
Units
mS
mS
mS
mS
mS
mS
mS
mS
mS
mS
Table 10 – Output Voltage Timing
Table 11 – Turn On/Off Timing
OP650
-
